Weight and Balance Calculator

Enter the weights. You can select lbs or kg for Front Seat, Back Seat, and Luggage. All calculations will be performed automatically using lbs.

Basic Empty Weight (lbs)

Arm: 86.4 in

Moment: 133660.8 lbs·in

Front Seat (lbs)

Arm: 80.5 in

Back Seat (lbs)

Arm: 118.1 in

Luggage (lbs)

Arm: 142.8 in

Fuel

Fuel to Load (gallons)

Arm: 95 in

Maximum Allowable Fuel

Maximum fuel that can be loaded: 48.0 gallons (288.0 lbs)

Note: Maximum fuel capacity is 48 gallons (288 lbs). Available fuel is limited by remaining weight capacity.

Pressure Altitude

Altimeter Setting (inHg)

Standard pressure: 29.92 inHg (1013.2078880000001 hPa)

Calculated Pressure Altitude

Enter altimeter setting to calculate

Totals

Total Weight:

1547.0 lbs

Total Moment:

133660.8 lbs·in

Total Arm:

86.40 in

Maximum Ramp Weight:

2550 lbs

✓ Weight within limits

Remaining capacity: 1003.0 lbs

Takeoff Weight and Balance

Takeoff Weight:

1539.0 lbs

Takeoff Moment:

132900.8 lbs·in

Takeoff Arm:

86.36 in

Note: Takeoff weight is ramp weight minus 8 lbs. Takeoff moment is ramp moment minus 760 lbs·in.

Landing Weight Calculation

Cruise Type

Flight Time (hours)

Landing Weight

Enter flight time to calculate landing weight
